LED專用定電流電源
分享到:
LED專用定電流電源
型號: T-LED
規格: 200mA、500mA或其它客制化規格
品牌: TOTC
市場價: 0.0
產品詳情


特點:採用每路單獨恒流輸出、每臺可點點20片基板、每片基板最多可同時點亮20顆產品,每片可單獨設定電流、時間、老化模式等參數,具有恆流、ON/OFFPulseTimer功能,數化位參數設定輸入,實時VFIF監測、電腦連線功能。適用於LED\LD晶片、燈珠的點亮老化測試


規格:單路輸出電流:200mA500mA或其它客制化規格

   電壓範圍:DC 5VDC 12V或客制化規格

   基板材質:FR4、鋁板、銅板,支架尺寸客制化

   選配:電腦實時監控功能、自動校正軟體、高頻電流源


Features: Each individual constant current output,each board can be little 20 per substrate can simultaneously lit 20 products,each piece can be set individually current, time, aging pattern and otherparameters, with a constant current, ON / OFF, Pulse, Timer function, thenumber of bits input parameter setting, real-VF, IF monitor, computerconnection function. Suitable for LED \ LD chip, lamp beads lit aging test


Specifications: Single Output Current: 200mA,500mA, or other customized specifications

Voltagerange: DC 5V, DC 12V or customized specifications

Substratematerial: FR4, aluminum, copper, frame size customization

Optional:PC real-time monitoring, automatic calibration software, high-frequency currentsource
